Seibu Giken America Desiccant Dehumidifier Rotors
D-MAX, SSCR-L, SZCR
MANUFACTURER’S SITE
D-MAX
40% higher moisture removal capacity.
Activated silica gel with controlled pore sizes synthesized into honeycomb matrix.
Works in 100% RH environments.
Up to 90% of the original dehumidifying capacity after 10 year of service.
Requires low reactivation energy per pound of moisture removal.
SSCR-L
Developed for AHU with low waste-heat.
Reactivation temperature below 80°C (176°F).
Specifically designed for low energy consumption.
Advanced matrix design to provide 20% to 30% lower pressure loss than competitive products.
SZCR
Synthesized Zeolite with high heat resistance.
Reactivation temperature up to 220°C (428°F).
Used for low dew point applications as well as for the hot air with high VOCs content.
Dew point temperature achieved with a single rotor: down to -80°C (-112°F).
The most advanced desiccant technology available in a dehumidifier rotor Advanced desiccant produced “in the flute,” encapsulating ceramic fiber substrate in a unique patented processChemically inert, nonshedding, washable rotorsApplications: commercial, industrial, low dew pointCapacity ranges from 50 to 50,000 scfm; 2″, 4″, 8″, 16″ thickness; diameters of 7″ – 166″
